9BBH | pdb_00009bbh

Co-crystal structure of human DDB1 bound to fragment UB028670


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.00 Å
  • R-Value Free:
    0.232 (Depositor), 0.240 (DCC)
  • R-Value Work:
    0.188 (Depositor), 0.200 (DCC)
  • R-Value Observed:
    0.190 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation   3D Report Full Report


Ligand Structure Quality Assessment

Created with Raphaël 2.3.0Worse 01 BetterLigand structure goodness of fit to experimental dataBest fitted VVPClick on this verticalbar to view details

This is version 1.1 of the entry. See complete history


Literature

Co-crystal structure of human DDB1 bound to fragment UB028670

Zeng, H.Dong, A.Frommlet, A.Seitova, A.Loppnau, P.Ackloo, S.Arrowsmith, C.H.Edwards, A.M.Halabelian, L.Structural Genomics Consortium (SGC)

To be published.

Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
DNA damage-binding protein 11,142Homo sapiensMutation(s): 0
Gene Names: DDB1XAP1
UniProt & NIH Common Fund Data Resources
Find proteins for Q16531 (Homo sapiens)
Explore Q16531
Go to UniProtKB:  Q16531
PHAROS:  Q16531
GTEx:  ENSG00000167986
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ16531
Sequence Annotations
Expand
  • Reference Sequence
Small Molecules
Ligands 4 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
TLA
Query on TLA

Download Ideal Coordinates CCD File
B [auth A],
C [auth A]
L(+)-TARTARIC ACID
C4 H6 O6
FEWJPZIEWOKRBE-JCYAYHJZSA-N
VVP (Subject of Investigation/LOI)
Query on VVP

Download Ideal Coordinates CCD File
D [auth A],
E [auth A]
4-methoxy-1H-indole
C9 H9 N O
LUNOXNMCFPFPMO-UHFFFAOYSA-N
EDO
Query on EDO

Download Ideal Coordinates CCD File
F [auth A],
G [auth A]
1,2-ETHANEDIOL
C2 H6 O2
LYCAIKOWRPUZTN-UHFFFAOYSA-N
UNX
Query on UNX

Download Ideal Coordinates CCD File
H [auth A],
I [auth A],
J [auth A],
K [auth A],
L [auth A]
UNKNOWN ATOM OR ION
X
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.00 Å
  • R-Value Free:  0.232 (Depositor), 0.240 (DCC)
  • R-Value Work:  0.188 (Depositor), 0.200 (DCC)
  • R-Value Observed: 0.190 (Depositor)
Space Group: P 21 21 21
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 62.924α = 90
b = 125.268β = 90
c = 168.529γ = 90
Software Package:
Software NamePurpose
REFMACrefinement
Aimlessdata scaling
PHASERphasing

Structure Validation

View Full Validation Report



Ligand Structure Quality Assessment

Created with Raphaël 2.3.0Worse 01 BetterLigand structure goodness of fit to experimental dataBest fitted VVPClick on this verticalbar to view details

Entry History & Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
Other private--

Revision History  (Full details and data files)

  • Version 1.0: 2024-06-12
    Type: Initial release
  • Version 1.1: 2024-10-23
    Changes: Structure summary
