9J2L | pdb_00009j2l

4,5-DOPA-extradiol-dioxygenase from Mirabilis jalapa


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.28 Å
  • R-Value Free:
    0.185 (Depositor), 0.185 (DCC)
  • R-Value Work:
    0.147 (Depositor), 0.148 (DCC)
  • R-Value Observed:
    0.148 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation   3D Report Full Report


Ligand Structure Quality Assessment


This is version 1.0 of the entry. See complete history


Literature

Structure-guided design of the dopamine biocatalyst from DOPA dioxygenase

Yeh, Y.C.Hsu, C.H.

To be published.

Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
4,5-DOPA dioxygenase extradiol
A, B, C
275Mirabilis jalapaMutation(s): 0
Gene Names: DOD
EC: 1.13.11.29
UniProt
Find proteins for B6F0W8 (Mirabilis jalapa)
Explore B6F0W8
Go to UniProtKB:  B6F0W8
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupB6F0W8
Sequence Annotations
Expand
  • Reference Sequence
Small Molecules
Ligands 5 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
CIT (Subject of Investigation/LOI)
Query on CIT

Download Ideal Coordinates CCD File
D [auth A],
EA [auth C],
S [auth B]
CITRIC ACID
C6 H8 O7
KRKNYBCHXYNGOX-UHFFFAOYSA-N
TRS
Query on TRS

Download Ideal Coordinates CCD File
F [auth A],
U [auth B]
2-AMINO-2-HYDROXYMETHYL-PROPANE-1,3-DIOL
C4 H12 N O3
LENZDBCJOHFCAS-UHFFFAOYSA-O
PEG
Query on PEG

Download Ideal Coordinates CCD File
Q [auth A],
R [auth A]
DI(HYDROXYETHYL)ETHER
C4 H10 O3
MTHSVFCYNBDYFN-UHFFFAOYSA-N
GOL
Query on GOL

Download Ideal Coordinates CCD File
AA [auth B]
BA [auth B]
CA [auth B]
DA [auth B]
G [auth A]
AA [auth B],
BA [auth B],
CA [auth B],
DA [auth B],
G [auth A],
GA [auth C],
H [auth A],
HA [auth C],
I [auth A],
IA [auth C],
J [auth A],
JA [auth C],
K [auth A],
KA [auth C],
L [auth A],
LA [auth C],
M [auth A],
MA [auth C],
N [auth A],
O [auth A],
P [auth A],
V [auth B],
W [auth B],
X [auth B],
Y [auth B],
Z [auth B]
GLYCEROL
C3 H8 O3
PEDCQBHIVMGVHV-UHFFFAOYSA-N
FE2 (Subject of Investigation/LOI)
Query on FE2

Download Ideal Coordinates CCD File
E [auth A],
FA [auth C],
T [auth B]
FE (II) ION
Fe
CWYNVVGOOAEACU-UHFFFAOYSA-N
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.28 Å
  • R-Value Free:  0.185 (Depositor), 0.185 (DCC)
  • R-Value Work:  0.147 (Depositor), 0.148 (DCC)
  • R-Value Observed: 0.148 (Depositor)
Space Group: P 43 21 2
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 142.37α = 90
b = 142.37β = 90
c = 131.628γ = 90
Software Package:
Software NamePurpose
PHENIXrefinement
HKL-2000data reduction
SCALEPACKdata scaling
PHASERphasing

Structure Validation

View Full Validation Report



Ligand Structure Quality Assessment


Entry History & Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
National Science Council (NSC, Taiwan)Taiwan111-2113-M-002-015-MY3
National Science Council (NSC, Taiwan)Taiwan111-2311-B-002-008-MY3

Revision History  (Full details and data files)

  • Version 1.0: 2025-08-13
    Type: Initial release
