9JTD | pdb_00009jtd

Crystal structure of PCoV-GD receptor binding domain complexed with fox ACE2

Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 3.59 Å
  • R-Value Free:
    0.263 (Depositor), 0.260 (DCC)
  • R-Value Work:
    0.229 (Depositor), 0.231 (DCC)
  • R-Value Observed:
    0.231 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation   3D Report Full Report


Ligand Structure Quality Assessment


This is version 1.0 of the entry. See complete history.


Literature

Crystal structure of PCoV-GD receptor binding domain complexed with fox ACE2

Jun, L., Xiaoyan, N.

To be published.

Macromolecules
Find similar proteins by:
(by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
Angiotensin-converting enzyme592Vulpes vulpesMutation(s): 0
Gene Names: ACE2
EC: 3.4
UniProt
Find proteins for A0A3Q7RAT9 (Vulpes vulpes)
Explore A0A3Q7RAT9
Go to UniProtKB:  A0A3Q7RAT9
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupA0A3Q7RAT9
Glycosylation
Glycosylation Sites: 3
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:
(by identity cutoff)  |  3D Structure
Entity ID: 2
MoleculeChains Sequence LengthOrganismDetailsImage
Spike glycoproteinB [auth E]194Pangolin coronavirusMutation(s): 0
Gene Names: S
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
Sequence Annotations
Expand
  • Reference Sequence
Oligosaccharides

Help

Entity ID: 3
MoleculeChains Length2D Diagram Glycosylation3D Interactions
beta-D-mannopyranose-(1-4)-2-acetamido-2-deoxy-beta-D-glucopyranose-(1-4)-2-acetamido-2-deoxy-beta-D-glucopyranoseC [auth B],
D [auth C]		3N-Glycosylation
Small Molecules
Ligands 1 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
NAG
Query on NAG
Download Ideal Coordinates CCD File
E [auth A]2-acetamido-2-deoxy-beta-D-glucopyranose
C8 H15 N O6
OVRNDRQMDRJTHS-FMDGEEDCSA-N
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 3.59 Å
  • R-Value Free:  0.263 (Depositor), 0.260 (DCC)
  • R-Value Work:  0.229 (Depositor), 0.231 (DCC)
  • R-Value Observed: 0.231 (Depositor)
Space Group: I 41 2 2
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 193.952α = 90
b = 193.952β = 90
c = 151.024γ = 90
Software Package:
Software NamePurpose
PHENIXrefinement
HKL-3000data reduction
HKL-3000data scaling
PHENIXphasing

Structure Validation

View Full Validation Report



Ligand Structure Quality Assessment


View more in-depth experimental data
Entry History & Funding Information

Deposition Data

Funding OrganizationLocationGrant Number
Not funded--

Revision History  (Full details and data files)

  • Version 1.0: 2025-10-22
    Type: Initial release
