8RIC | pdb_00008ric

Crystallographic structure of oligosaccharide dehydrogenase from Pycnoporus cinnabarinus bound to Sinapic Acid, tetragonal crystal

PDB DOI: https://doi.org/10.2210/pdb8RIC/pdb

Classification: OXIDOREDUCTASE
Organism(s): Trametes cinnabarina
Expression System: Aspergillus niger
Mutation(s): No

Deposited: 2023-12-18 Released: 2025-07-02
Deposition Author(s): Savino, C., Sciara, G., Gugole, E., Vallone, B., Fata, F., Bulfaro, G., Costanzo, A., Montemiglio, L.C.
Funding Organization(s): Not funded

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 1.86 Å
R-Value Free:
0.202 (Depositor), 0.205 (DCC)
R-Value Work:
0.169 (Depositor), 0.172 (DCC)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Ligand Structure Quality Assessment

This is version 1.0 of the entry. See complete history.

Literature

Towards an understanding of microbial lignin breakdown: fungal flavoenzymes prevent laccase-mediated polymerization of phenolic compounds

Savino, C., Sciara, G., Gugole, E., Vallone, B., Fata, F., Bulfaro, G., Costanzo, A., Montemiglio, L.C., Record, E.

To be published.

Macromolecule Content

Total Structure Weight: 133.17 kDa
Atom Count: 11,151
Modeled Residue Count: 1,182
Deposited Residue Count: 1,182
Unique protein chains: 1

Macromolecules

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Glucose oxidase	A, B	591	Trametes cinnabarina	Mutation(s): 0 Gene Names: BN946_scf184803.g17
UniProt
Find proteins for A0A060SC37 (Pycnoporus cinnabarinus) Explore A0A060SC37 Go to UniProtKB: A0A060SC37
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt Group	A0A060SC37
Glycosylation
Glycosylation Sites: 2	Glycosylation Focus chain A Focus chain B
Sequence Annotations Expand
Reference Sequence

Oligosaccharides

Help

Entity ID: 2
Molecule	Chains	Length	2D Diagram	Glycosylation	3D Interactions
2-acetamido-2-deoxy-beta-D-glucopyranose-(1-4)-2-acetamido-2-deoxy-beta-D-glucopyranose	C, E [auth F], F [auth G]	2		N-Glycosylation	Interactions Focus chain C Focus chain E [auth F] Focus chain F [auth G] Interactions & Density Focus chain C Focus chain E [auth F] Focus chain F [auth G]

Entity ID: 3
Molecule	Chains	Length	2D Diagram	Glycosylation	3D Interactions
alpha-D-mannopyranose-(1-6)-beta-D-mannopyranose-(1-4)-2-acetamido-2-deoxy-beta-D-glucopyranose-(1-4)-2-acetamido-2-deoxy-beta-D-glucopyranose	D [auth E], G [auth H]	4		N/A	Interactions Focus chain D [auth E] Focus chain G [auth H] Interactions & Density Focus chain D [auth E] Focus chain G [auth H]

Small Molecules

Ligands 4 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
FAD (Subject of Investigation/LOI) Query on FAD Download Ideal Coordinates CCD File SDF format, chain H [auth A] SDF format, chain W [auth B] MOL2 format, chain H [auth A] MOL2 format, chain W [auth B] mmCIF format, chain H [auth A] mmCIF format, chain W [auth B]	H [auth A], W [auth B]	FLAVIN-ADENINE DINUCLEOTIDE C₂₇ H₃₃ N₉ O₁₅ P₂ VWWQXMAJTJZDQX-UYBVJOGSSA-N		Interactions Focus chain H [auth A] Focus chain W [auth B] Interactions & Density Focus chain H [auth A] Focus chain W [auth B]
SXX (Subject of Investigation/LOI) Query on SXX Download Ideal Coordinates CCD File SDF format, chain AA [auth B] SDF format, chain I [auth A] SDF format, chain J [auth A] SDF format, chain K [auth A] SDF format, chain X [auth B] SDF format, chain Y [auth B] SDF format, chain Z [auth B] MOL2 format, chain AA [auth B] MOL2 format, chain I [auth A] MOL2 format, chain J [auth A] MOL2 format, chain K [auth A] MOL2 format, chain X [auth B] MOL2 format, chain Y [auth B] MOL2 format, chain Z [auth B] mmCIF format, chain AA [auth B] mmCIF format, chain I [auth A] mmCIF format, chain J [auth A] mmCIF format, chain K [auth A] mmCIF format, chain X [auth B] mmCIF format, chain Y [auth B] mmCIF format, chain Z [auth B]	AA [auth B] I [auth A] J [auth A] K [auth A] X [auth B] AA [auth B], I [auth A], J [auth A], K [auth A], X [auth B], Y [auth B], Z [auth B]	SINAPINATE C₁₁ H₁₂ O₅ PCMORTLOPMLEFB-ONEGZZNKSA-N		Interactions Focus chain AA [auth B] Focus chain I [auth A] Focus chain J [auth A] Focus chain K [auth A] Focus chain X [auth B] Focus chain Y [auth B] Focus chain Z [auth B] Interactions & Density Focus chain AA [auth B] Focus chain I [auth A] Focus chain J [auth A] Focus chain K [auth A] Focus chain X [auth B] Focus chain Y [auth B] Focus chain Z [auth B]
NAG Query on NAG Download Ideal Coordinates CCD File SDF format, chain V [auth A] MOL2 format, chain V [auth A] mmCIF format, chain V [auth A]	V [auth A]	2-acetamido-2-deoxy-beta-D-glucopyranose C₈ H₁₅ N O₆ OVRNDRQMDRJTHS-FMDGEEDCSA-N		Interactions Focus chain V [auth A] Interactions & Density Focus chain V [auth A]
SO4 Query on SO4 Download Ideal Coordinates CCD File SDF format, chain BA [auth B] SDF format, chain CA [auth B] SDF format, chain DA [auth B] SDF format, chain EA [auth B] SDF format, chain FA [auth B] SDF format, chain GA [auth B] SDF format, chain HA [auth B] SDF format, chain IA [auth B] SDF format, chain JA [auth B] SDF format, chain KA [auth B] SDF format, chain L [auth A] SDF format, chain M [auth A] SDF format, chain N [auth A] SDF format, chain O [auth A] SDF format, chain P [auth A] SDF format, chain Q [auth A] SDF format, chain R [auth A] SDF format, chain S [auth A] SDF format, chain T [auth A] SDF format, chain U [auth A] MOL2 format, chain BA [auth B] MOL2 format, chain CA [auth B] MOL2 format, chain DA [auth B] MOL2 format, chain EA [auth B] MOL2 format, chain FA [auth B] MOL2 format, chain GA [auth B] MOL2 format, chain HA [auth B] MOL2 format, chain IA [auth B] MOL2 format, chain JA [auth B] MOL2 format, chain KA [auth B] MOL2 format, chain L [auth A] MOL2 format, chain M [auth A] MOL2 format, chain N [auth A] MOL2 format, chain O [auth A] MOL2 format, chain P [auth A] MOL2 format, chain Q [auth A] MOL2 format, chain R [auth A] MOL2 format, chain S [auth A] MOL2 format, chain T [auth A] MOL2 format, chain U [auth A] mmCIF format, chain BA [auth B] mmCIF format, chain CA [auth B] mmCIF format, chain DA [auth B] mmCIF format, chain EA [auth B] mmCIF format, chain FA [auth B] mmCIF format, chain GA [auth B] mmCIF format, chain HA [auth B] mmCIF format, chain IA [auth B] mmCIF format, chain JA [auth B] mmCIF format, chain KA [auth B] mmCIF format, chain L [auth A] mmCIF format, chain M [auth A] mmCIF format, chain N [auth A] mmCIF format, chain O [auth A] mmCIF format, chain P [auth A] mmCIF format, chain Q [auth A] mmCIF format, chain R [auth A] mmCIF format, chain S [auth A] mmCIF format, chain T [auth A] mmCIF format, chain U [auth A]	BA [auth B] CA [auth B] DA [auth B] EA [auth B] FA [auth B] BA [auth B], CA [auth B], DA [auth B], EA [auth B], FA [auth B], GA [auth B], HA [auth B], IA [auth B], JA [auth B], KA [auth B], L [auth A], M [auth A], N [auth A], O [auth A], P [auth A], Q [auth A], R [auth A], S [auth A], T [auth A], U [auth A]	SULFATE ION O₄ S QAOWNCQODCNURD-UHFFFAOYSA-L		Interactions Focus chain BA [auth B] Focus chain CA [auth B] Focus chain DA [auth B] Focus chain EA [auth B] Focus chain FA [auth B] Focus chain GA [auth B] Focus chain HA [auth B] Focus chain IA [auth B] Focus chain JA [auth B] Focus chain KA [auth B] Focus chain L [auth A] Focus chain M [auth A] Focus chain N [auth A] Focus chain O [auth A] Focus chain P [auth A] Focus chain Q [auth A] Focus chain R [auth A] Focus chain S [auth A] Focus chain T [auth A] Focus chain U [auth A] Interactions & Density Focus chain BA [auth B] Focus chain CA [auth B] Focus chain DA [auth B] Focus chain EA [auth B] Focus chain FA [auth B] Focus chain GA [auth B] Focus chain HA [auth B] Focus chain IA [auth B] Focus chain JA [auth B] Focus chain KA [auth B] Focus chain L [auth A] Focus chain M [auth A] Focus chain N [auth A] Focus chain O [auth A] Focus chain P [auth A] Focus chain Q [auth A] Focus chain R [auth A] Focus chain S [auth A] Focus chain T [auth A] Focus chain U [auth A]
