9IL7 | pdb_00009il7

Crystal Structure of SME E166A in Complex with Ceftaroline Fosamil

PDB DOI: https://doi.org/10.2210/pdb9IL7/pdb

Classification: HYDROLASE
Organism(s): Serratia marcescens
Expression System: Escherichia coli BL21(DE3)
Mutation(s): Yes

Deposited: 2024-06-29 Released: 2025-07-02
Deposition Author(s): Dhankhar, K., Hazra, S.
Funding Organization(s): Board of Research in Nuclear Sciences (BRNS), Indian Council of Medical Research

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 2.40 Å
R-Value Free:
0.260 (Depositor), 0.259 (DCC)
R-Value Work:
0.190 (Depositor), 0.190 (DCC)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Ligand Structure Quality Assessment

This is version 1.0 of the entry. See complete history.

Literature

Crystal Structure of SME E166A in Complex with Ceftaroline Fosamil

Dhankhar, K., Hazra, S.

To be published.

Macromolecule Content

Total Structure Weight: 64.09 kDa
Atom Count: 4,425
Modeled Residue Count: 534
Deposited Residue Count: 550
Unique protein chains: 1

Macromolecules

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
beta-lactamase	A, B	275	Serratia marcescens	Mutation(s): 1 Gene Names: sme-2, blaSME-1, blaSME-4, blaSME1, SME12620_22 EC: 3.5.2.6
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 7 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
A1L2O (Subject of Investigation/LOI) Query on A1L2O Download Ideal Coordinates CCD File SDF format, chain C [auth A] SDF format, chain N [auth B] MOL2 format, chain C [auth A] MOL2 format, chain N [auth B] mmCIF format, chain C [auth A] mmCIF format, chain N [auth B]	C [auth A], N [auth B]	(2~{R})-2-[(1~{R})-1-[[(2~{Z})-2-ethoxyimino-2-[5-(phosphonoamino)-1,2,4-thiadiazol-3-yl]ethanoyl]amino]-2-oxidanylidene-ethyl]-5-[[4-(1-methylpyridin-4-yl)-1,3-thiazol-2-yl]sulfanyl]-3,6-dihydro-2~{H}-1,3-thiazine-4-carboxylic acid C₂₂ H₂₄ N₈ O₈ P S₄ FPOBTJLCBVZDBU-WMEYXJDLSA-O		Interactions Focus chain C [auth A] Focus chain N [auth B] Interactions & Density Focus chain C [auth A] Focus chain N [auth B]
PG4 (Subject of Investigation/LOI) Query on PG4 Download Ideal Coordinates CCD File SDF format, chain Q [auth B] MOL2 format, chain Q [auth B] mmCIF format, chain Q [auth B]	Q [auth B]	TETRAETHYLENE GLYCOL C₈ H₁₈ O₅ UWHCKJMYHZGTIT-UHFFFAOYSA-N		Interactions Focus chain Q [auth B] Interactions & Density Focus chain Q [auth B]
IOD (Subject of Investigation/LOI) Query on IOD Download Ideal Coordinates CCD File SDF format, chain U [auth B] MOL2 format, chain U [auth B] mmCIF format, chain U [auth B]	U [auth B]	IODIDE ION I XMBWDFGMSWQBCA-UHFFFAOYSA-M		Interactions Focus chain U [auth B] Interactions & Density Focus chain U [auth B]
PEG (Subject of Investigation/LOI) Query on PEG Download Ideal Coordinates CCD File SDF format, chain D [auth A] SDF format, chain O [auth B] SDF format, chain P [auth B] SDF format, chain R [auth B] SDF format, chain S [auth B] SDF format, chain T [auth B] MOL2 format, chain D [auth A] MOL2 format, chain O [auth B] MOL2 format, chain P [auth B] MOL2 format, chain R [auth B] MOL2 format, chain S [auth B] MOL2 format, chain T [auth B] mmCIF format, chain D [auth A] mmCIF format, chain O [auth B] mmCIF format, chain P [auth B] mmCIF format, chain R [auth B] mmCIF format, chain S [auth B] mmCIF format, chain T [auth B]	D [auth A] O [auth B] P [auth B] R [auth B] S [auth B] D [auth A], O [auth B], P [auth B], R [auth B], S [auth B], T [auth B]	DI(HYDROXYETHYL)ETHER C₄ H₁₀ O₃ MTHSVFCYNBDYFN-UHFFFAOYSA-N		Interactions Focus chain D [auth A] Focus chain O [auth B] Focus chain P [auth B] Focus chain R [auth B] Focus chain S [auth B] Focus chain T [auth B] Interactions & Density Focus chain D [auth A] Focus chain O [auth B] Focus chain P [auth B] Focus chain R [auth B] Focus chain S [auth B] Focus chain T [auth B]
PO4 (Subject of Investigation/LOI) Query on PO4 Download Ideal Coordinates CCD File SDF format, chain FA [auth B] SDF format, chain GA [auth B] SDF format, chain HA [auth B] SDF format, chain L [auth A] SDF format, chain M [auth A] MOL2 format, chain FA [auth B] MOL2 format, chain GA [auth B] MOL2 format, chain HA [auth B] MOL2 format, chain L [auth A] MOL2 format, chain M [auth A] mmCIF format, chain FA [auth B] mmCIF format, chain GA [auth B] mmCIF format, chain HA [auth B] mmCIF format, chain L [auth A] mmCIF format, chain M [auth A]	FA [auth B], GA [auth B], HA [auth B], L [auth A], M [auth A]	PHOSPHATE ION O₄ P NBIIXXVUZAFLBC-UHFFFAOYSA-K		Interactions Focus chain FA [auth B] Focus chain GA [auth B] Focus chain HA [auth B] Focus chain L [auth A] Focus chain M [auth A] Interactions & Density Focus chain FA [auth B] Focus chain GA [auth B] Focus chain HA [auth B] Focus chain L [auth A] Focus chain M [auth A]
CL (Subject of Investigation/LOI) Query on CL Download Ideal Coordinates CCD File SDF format, chain AA [auth B] SDF format, chain BA [auth B] SDF format, chain CA [auth B] SDF format, chain DA [auth B] SDF format, chain E [auth A] SDF format, chain F [auth A] SDF format, chain G [auth A] SDF format, chain H [auth A] SDF format, chain I [auth A] SDF format, chain J [auth A] SDF format, chain K [auth A] SDF format, chain V [auth B] SDF format, chain W [auth B] SDF format, chain X [auth B] SDF format, chain Y [auth B] SDF format, chain Z [auth B] MOL2 format, chain AA [auth B] MOL2 format, chain BA [auth B] MOL2 format, chain CA [auth B] MOL2 format, chain DA [auth B] MOL2 format, chain E [auth A] MOL2 format, chain F [auth A] MOL2 format, chain G [auth A] MOL2 format, chain H [auth A] MOL2 format, chain I [auth A] MOL2 format, chain J [auth A] MOL2 format, chain K [auth A] MOL2 format, chain V [auth B] MOL2 format, chain W [auth B] MOL2 format, chain X [auth B] MOL2 format, chain Y [auth B] MOL2 format, chain Z [auth B] mmCIF format, chain AA [auth B] mmCIF format, chain BA [auth B] mmCIF format, chain CA [auth B] mmCIF format, chain DA [auth B] mmCIF format, chain E [auth A] mmCIF format, chain F [auth A] mmCIF format, chain G [auth A] mmCIF format, chain H [auth A] mmCIF format, chain I [auth A] mmCIF format, chain J [auth A] mmCIF format, chain K [auth A] mmCIF format, chain V [auth B] mmCIF format, chain W [auth B] mmCIF format, chain X [auth B] mmCIF format, chain Y [auth B] mmCIF format, chain Z [auth B]	AA [auth B] BA [auth B] CA [auth B] DA [auth B] E [auth A] AA [auth B], BA [auth B], CA [auth B], DA [auth B], E [auth A], F [auth A], G [auth A], H [auth A], I [auth A], J [auth A], K [auth A], V [auth B], W [auth B], X [auth B], Y [auth B], Z [auth B]	CHLORIDE ION Cl VEXZGXHMUGYJMC-UHFFFAOYSA-M		Interactions Focus chain AA [auth B] Focus chain BA [auth B] Focus chain CA [auth B] Focus chain DA [auth B] Focus chain E [auth A] Focus chain F [auth A] Focus chain G [auth A] Focus chain H [auth A] Focus chain I [auth A] Focus chain J [auth A] Focus chain K [auth A] Focus chain V [auth B] Focus chain W [auth B] Focus chain X [auth B] Focus chain Y [auth B] Focus chain Z [auth B] Interactions & Density Focus chain AA [auth B] Focus chain BA [auth B] Focus chain CA [auth B] Focus chain DA [auth B] Focus chain E [auth A] Focus chain F [auth A] Focus chain G [auth A] Focus chain H [auth A] Focus chain I [auth A] Focus chain J [auth A] Focus chain K [auth A] Focus chain V [auth B] Focus chain W [auth B] Focus chain X [auth B] Focus chain Y [auth B] Focus chain Z [auth B]
NA (Subject of Investigation/LOI) Query on NA Download Ideal Coordinates CCD File SDF format, chain EA [auth B] MOL2 format, chain EA [auth B] mmCIF format, chain EA [auth B]	EA [auth B]	SODIUM ION Na FKNQFGJONOIPTF-UHFFFAOYSA-N		Interactions Focus chain EA [auth B] Interactions & Density Focus chain EA [auth B]
